Description
AC INPUT
* AC Input Capacity on Battery 800VA
* AC Input Voltage : 115V +/- 25% at line input
* AC Input Frequency 50 or 60 Hz+/-5% (auto sensing)
OUTPUT
* Output No Of Sockets : 3 Battery Backup +1 Surge Protection
AC OUTPUT
* AC Output Voltage : Simulated sine wave at 115V +/- 5%
* AC Output Frequency: 50 or 60 Hz +/- 0.5%
* AC Output Voltage Regulation: AVR automatically increase output voltage 15% above input voltage if -9% to -25% of nominal. AVR decrease output voltage 13% below input voltage if +9% to +25% of nominal
* AC Output Transfer 2/4 milliseconds, including detection time
PROTECTION
* Protection Spike: 480 Joules / 2ms
* Protection Overload: UPS automatic shutdown if overload exceeds 110% nominal at 60 sec and 130% at 3 sec
* Protection Unit: Fuse for overload & short circuit protection
* Protection Inside Protection: UPS output cut off immediately or input fuse protection
BATTERY
* Battery Type Sealed, Maintenance-free lead acid batteries with 3-6 year typical lifetime
* Battery Typical 6 hours (to 90% of full capacity)
* Battery Protection Auto discharge protection
Battery DC Voltage: 12V
BACKUP TIME
* Battery Backup Time Full Load: 6 minutes
* Battery Backup Time Half Load: 13 minutes
PHYSICAL
* Weight: 13Kg (28.6lbs)
* Dimension: 97x320x135mm (3.8x12.8x5.3")
ALARM
* Alarm Battery Backup: Slow beeping sound (about 0.47 Hz)
* Alarm Battery Low: Rapid beeping sound (about 1.82Hz)
* Alarm Overload: Continue beeping sound
INTERFACE
* Interface RS-232 : YES
ENVIRONMENT
* Environment Ambient 3,500 meters max. elevation, 0-95% humidity non-condensing, 0-40 deg C
* Environment Audible <40dBA (1 meter from surface)
